CCX118 Dynamic FPD C-arm System

Core Overview

CCX118 is a professional smart dynamic flat panel detector (FPD) C-arm system featuring a state-of-the-art imported dynamic FPD, independent-developed high-frequency high-voltage generator and advanced digital image processing technology. It integrates low-dose radiation, high-quality imaging, humanized operation and intelligent system connection, with a friendly user interface and complete mechanical movement flexibility. Suitable for a variety of surgical and clinical examination scenarios, it supports seamless docking with hospital information systems, remote maintenance and diagnosis, and provides safe and efficient imaging support for minimally invasive and conventional surgeries with 50%-80% radiation dose reduction.

Ⅰ. Core Technical Specifications

1. Power & Electrical Performance

• High frequency inverter power supply: 5.0kW power, 110kHz main inverter frequency
• Automatic fluoroscopy: Tube voltage 40kv~120kv (auto-adjust), tube current 0.3mA~~4mA (auto-adjust)
• Manual fluoroscopy: Tube voltage 40kv~120kv (continuous), tube current 0.3mA~~4mA (continuous)
• Pulse fluoroscopy: Tube current 0.3mA~~30mA (continuous)
• Photography parameters: 40KV~120KV tube voltage, 25mA~100mA tube current, 1.0mAs~280mAs

2. Core Components

• X-ray tube: High frequency special tube; fluoroscopy focus 0.3/1.5mm; thermal capacity 650kJ (867kHu)
• Detector: Imported 9*9 inch dynamic flat panel detector (larger view, higher resolution, lower noise)
• Monitor: 3 pcs 19 inch IM medical LCD grayscale display
• Imaging system: Mega-pixel CCU; supports real-time acquisition, multi-image storage, LIH (last image freeze)

3. Structure & Mechanical Movement (C-arm)

• Wheels: Direction wheel (360° rotatable), main wheel (±90° rotatable)
• Pillar: 400mm up & down electrical stroke
• C-arm movement: Forward/backward 200mm; horizontal axis revolution ±180°; vertical axis revolution ±15°; focus to screen distance 1000mm; open distance 800mm; arc depth 660mm; orbital slipping 135°

4. Workstation Software Functions

Supports image W/L adjustment, grayscale conversion, ROI balance, rotation, noise reduction, enhancement, smoothing, sharpening, compression, zoom; with measurement, marking, print layout functions; compatible with DICOM image sending/printing and movie playback.

Ⅱ. Core Product Advantages

1. Intelligent Low-Dose Radiation Technology Independent-developed high-frequency high-voltage generator with intelligent frequency conversion low-dose pulse perspective technology, reducing radiation dose by 50%-80% while improving image quality, providing double safety for operators and patients. Configured with low-dose mode: Matches high-quality image chain, adopts part-specific image processing and dose/frequency adjustment, ensuring imaging quality with lower surgical space radiation. Separate the room exposure with pulse fluoroscopy: Realizes low-dose, clearer imaging, meeting the precision requirements of high-difficulty minimally invasive surgeries.
2. High-Performance Imaging & Processing Equipped with imported 9*9 inch dynamic FPD and perfect digital imaging chain, featuring larger view, higher resolution and lower noise for accurate clinical diagnosis. RCDP (rapid calculate display platform): GPU-based dynamic real-time image processing technology, enabling sharp imaging for various human body parts. Rich imaging functions: Real-time acquisition, last image freeze, image patching, multi-directional image adjustment, and comprehensive post-processing tools to meet surgical and diagnostic needs.
3. Humanized & Efficient Operation Design Human graphic LCD touch-screen: Realizes accurate APR parameter setting with simple and convenient operation. C-arm stand hand controller: Enables remote control of mechanical and collimator movement, optimizing workflow without the need to approach the equipment. Flexible 6-dimensional mechanical movement of C-arm: Adapts to various surgical positioning requirements, with a large movement range to meet different clinical scenarios (spine, pelvis, limbs fluoroscopy, etc.). DSI (Digital Spot Film) & red light cross localization: Improves the accuracy of lesion positioning and spot imaging, avoiding missed diagnosis.
4. Intelligent System Connection & Maintenance Seamless cloud PACS system docking: Realizes image information sharing, remote diagnosis, and connection with hospital HIS system, outpatient service, academic communication platforms and other instruments/ departments. Remote maintenance & self-diagnosis: Supports remote system maintenance; with self-diagnosis function and error-code display, enabling quick fault location and resolution. DICOM standard compatibility: Realizes DICOM image sending, printing and storage, integrating with hospital digital information management system.

Ⅲ. Core Clinical Applications

Suitable for a variety of clinical departments and surgical scenarios, including spine surgery, pain surgery, orthopedic surgery, traumatology surgery, gastroenterology, gynecology, urinary surgery; supports fluoroscopy and spot imaging of lumbar vertebrae, pelvis, limbs and other body parts, applicable for both high-precision minimally invasive surgeries and routine surgical/ diagnostic fluoroscopy, meeting the diverse imaging needs of operating rooms and clinical departments.
