Summary of CCC‑SW3303 Digital Optical Colposcope

Product Overview

CCC‑SW3303 digital optical colposcope is an opto‑electronic high‑tech diagnostic system integrating computer, optics, imaging and ergonomics. It performs precise assessment of invisible lesion areas and delivers comprehensive solutions for gynecological disease diagnosis and treatment.

Application Scope

‑ Vaginal exfoliative cytology smear with Pap grade III or higher.
‑ Negative cytology result but cancer‑suspected lesions under naked‑eye inspection.
‑ Poor therapeutic effect after long‑term cervicitis treatment.
‑ Tiny‑structure lesions hard to identify by visual observation.
‑ Locating lesion scope before cervical‑cancer surgery.

Main Apparatus Features

1. Imaging hardware: Adopts Sony Exview HAD high‑speed auto‑focus CCD for fast tracking, capture and observation of subtle image changes. Wide‑depth‑of‑field design for three‑dimensional observation. Ultra‑high‑brightness circular LED shadow‑free light source with adjustable illuminance and color temperature for true‑to‑tissue‑morphology images.
2. System control: Supports continuous optical zoom, magnification display, acetic‑acid reaction timing, electronic green‑light source, image freeze. Realizes quantitative control of examination workflow and image analysis, reduces dependence on individual operator experience, facilitates standardization and popularization of colposcopy.
3. Data statistics: Built‑in SQL‑Server‑based data management, provides statistical analysis of patient data for review, research and teaching.

Software Functions

‑ Real‑time preview, image freeze, capture, processing, pseudo‑color rendering, measurement, comparison, saving and editing.
‑ Rapid report editing; built‑in expert‑diagnosis thesaurus and report templates.
‑ Unlimited‑duration dynamic‑video recording and storage; supports storing over 300 000 cases.
‑ C/S‑architecture database server; compatible with PACS system, complete network‑related functions.
‑ Embedded standard anatomical diagrams and typical‑case reference images to assist clinical diagnosis.

Performance Parameters

‑ Camera: Sony Exview HAD CCD, 800 000 pixels, horizontal resolution ≥480 lines, SNR 52 dB.
‑ Focus distance: standard 200‑500 mm, expandable 150‑550 mm.
‑ Zoom: 18× optical zoom, 12× digital zoom; total magnification up to 216×.
‑ Field‑of‑view diameter: 2.5‑320 mm.
‑ Auto white‑balance; multi‑point circular LED light source; auto / manual focus.
‑ Output: S‑Video, composite‑video, PAL format; RS232 illumination control.

Logistics & Commercial Terms

‑ Packing dimension: 54 × 63 × 109 cm; gross weight 60 kg.
‑ Warranty: 18 months.
‑ Payment: advance T/T; delivery: 3‑5 working‑days upon receipt of payment.

Manufacturer: China Care Medical Equipment Co.,Ltd Address: Room B101, ZhongBang Business Building, PuXing Road No. 87, Tianhe, Guangzhou, China Website: www.chinacaremedical.com
