Product info
- Product name:Full-digital Color Doppler Ultrasound Diagnostic System
- Product code:CCB-9200D
Out of stock. Request a quote.
Request a Quote
Packaging Specifications
Core Parameters
Description
Full-Size Color Doppler Ultrasound Scanner Specification
Standard Configuration
- Main Unit
- 15" LCD Monitor
- 2 probe connectors
- 500GB Hard Disk
- 2 USB ports
- Convex Probe (included)
Core Technical Features
1. Display & Imaging Modes
- B/W Imaging: B, B/B, 4B, left/right B/M, B/D, PW; local zoom in M-mode
- Color Blood Flow (CFM): B/C, BC/B, B/BC
- Spectral Doppler: B/D, B/C/D, PW
2. Probe Specifications
- Socket Count: 4 probe connectors
- Frequency Range: 2.0MHz – 10.0MHz, with 8-stage multi-frequency control
- Supported Types: Large convex, slight convex, linear array, endocavity
- Acoustic Power: 16-stage adjustable output
3. Focus & Depth Control
- Focusing: Electronic + acoustic lens focusing
- Transmission Focus: Single, double, 3-focus, 4-focus
- Continuous dynamic focusing for front-end reception
- Display Depth: Continuously adjustable via encoder
4. Image Processing & Specifications
- Digital Beamforming:
- Doppler & Signal Processing:
- Image Processing:
- Image Resolution:
Physical Specifications
- Dimensions & Weight:
Optional Accessories
- 3.5MHz Convex probe
- 6.5MHz Transvaginal probe
- 7.5MHz Linear probe
- 3.5MHz Phase array cardiac probe
- 3.5MHz Micro-convex probe
- DICOM 3.0 upgrade
- Printer
