Description

Characteristics:
·Professional digital camera is more sensitive to the changes of patient’s eyes, even the smallest changes.
·14mm aperture provides broader and clearer field of view.
·Importedoptics from Germany reduces optical distortion, increases clarity and depth of focus.
·All the Optical lenses are moistureproof, mildewproof and anti-reflected treated.
Osram bulb provides the low heating, high brightness and even lighting.
·Five-step drum magnification for eyepiece. Sclera vein could be observed under the 40x magnification
·Excellent optical performances and long span usage.
·Anti-ultraviolet radiation filter ensures patient’s safety during examination.
·All the joints can be connected by accessories with international standards.

Specifications:

Microscope Type	Galilean stereoscopic microscope
Objective Magnification	Five-step Drum Magnification
Eye Piece	12.5x
Magnifications (Field of View)	6x（φ33mm）、10x（φ22.5mm）、16x（φ14mm）、25x（φ8.8mm）、40x（φ5.5mm）
Pupil Distance	55mm~75mm
Diopter Adjustment	-5D~+3D
Slit Width	0mm~14mm adjustable( slit is round when the slit width is 14mm)
Slit Height	1mm~14mm adjustable
Slit Angle	0°~180° adjustable
Slit Inclination	5°、10°、15°、20°
Diameter of Light Spot	φ14mm、φ10mm、φ5mm、φ2mm、φ1mm、φ0.2mm
Filter	Heat Absorption, Grey, Red Free, Cobalt Blue
Input Voltage	AC220V±22 V；AC110V±11 V
Electrical Safety Standard	Executive Standard: IEC601－1,Class I,Type B
Packing Volume	720mmx495mmx480mm
Total Weight	24Kg
Optional Accessories	Applanation Tonometer、Measuring Eye Piece ,Trihedron Lens、Gonioscope、Funduscope、Aspheric Lens、Teaching Tube
