Description

Technologies And Powerful Functions Simple operation interface provides with accurate operation experience.

automatic operation without handle, one finger touch get all results automatically

compact design with computer build in

micron level ensure accurate eye axial length measurement

biological progress analysis available built-in

thermal printer

Specification

Measuring Range

axial length 14-38mm

Corneal curvature 5-11mm

Anterior chamber depth 0.7-8mm

Lens thickness 1-10mm(lens) 0.13-2.5mm(intraocular lens)

Center cornea thickness 0.2-1.2mm

Cornea white to white 7-16mm Pupil diameter 2-13mm

Curvature range 180 degree

Accuracy

Axial length 0.01mm

Corneal curvature 0.01mm Anterior chamber depth 0.01mm

Lens thickness 0.01mm Axial length 0.01mm

Center cornea thickness 0.01mm

White to white 0.01mm

Pupil diameter 0.01mm

Axis of sight eccentricity 0.01mm

Axis angle 1 degree

Repeatability

Axial length 0.02mm

Corneal curvature (1σ)+/-30μm

Anterior chamber depth 0.02mm

Lens thickness 0.02mm

Center cornea thickness 0.02mm

White to white (1σ)+/-0.3μm

Curvature difference ±9

degree Better Detail For Better Quality Better Detail For Better Quality CE FDA
