Description

Digital Vision Tester

New Technologies And Powerful Functions Simple operation interface provides with accurate operation experience.

Key Advantages

ADVANCED STRUCTURAL DESIGN

Designed for professional clinical use, the product offers precise and stable performance. Equipped with a horizontal bubble level, adjustable headrest, and ergonomic patient support frame, it ensures accurate alignment and comfortable refraction testing. All patient-contact areas are made of high-grade ABS material for easy cleaning and long-term hygiene.

INTELLIGENT CONTROL SYSTEM

The system integrates multiple operating modes including auxiliary lens mode, binocular function testing, and adjustable PD input mode. Customizable system settings such as step size, timing, and Bluetooth configuration enhance flexibility for different clinical environments.

SMART DISPLAY & OPERATION

The tablet APP interface displays real-time test information and system status. Functional touch keys allow smooth and intuitive operation, improving workflow efficiency during refraction procedures.

AUTOMATIC SELF-TEST FUNCTION

Upon startup, the system performs an automatic self-test to quickly enter working condition. Connection status of linked devices is clearly indicated on-screen, ensuring reliable operation at all times.

WIRELESS BLUETOOTH TRANSMISSION

Featuring a built-in Bluetooth module, the device connects wirelessly to the dedicated vision chart projector, eliminating cable clutter. Stable and fast data transmission ensures seamless communication between devices and supports a fully digital refraction environment.

EFFICIENT AND PRACTICAL DESIGN

The mounting bracket offers secure installation on refraction units. User-friendly positioning controls enable precise horizontal and optical alignment. Near-vision illumination and clear optical windows enhance accuracy during testing.

WIRELESS DATA TRANSMISSION

It can transmit data with other LINK devices, making optometry more convenient.

Specifications

Measure scope

Sphere: 0~±25D 0.01/0.12\0.25D steps

Cylinder: 0~±8.00D 0.01/0.12\0.25D steps

Axis: 0°~180° (1°step)

ADD: 0~+9.99D 0.01/0.12\0.25D steps

prism degree: 0~15Δ 0.01\0.12\0.25Δ steps

mode

cylinder: +,+/-, -

prism: X-Y,P-B

Contact lens: Softhard

Measuring mode: Single/progressive/ automatic recognition contact lens

Others

Diameter of lens: Ø 20~108mm

PD: 45~90mm, 0.25mm steps

Speed: 0.1S

ABBE: 30~80

Display: TFT LCD (5.6")

Printer: Thermal print

Dimensions: 222(D)*161(W)*372(H)mm

Package: 515(H)*320(W)*350(D)mm

Weight: ~5KG

Power supply: 100~120V/200~220V 50/60HZ

Features

Compact and lightTilting TFT color LCD touch screen (5.6 inch), clear view, easy and convenient operation.Built-in thermal printer, and also can be connected to computer, and display the data on computer.Built-in UV testerPD measuringAutomatic recognition of single and progressive lensMemory Function
