Description

echnical Parameters

• Illumination: 40,000–160,000 Lux
• LED Quantity: 61 pcs
• LED Type: German OSRAM LED bulb
• Average Service Life: ≥80,000 hours
• Color Temperature: 3700K–5000K
• Color Rendering Index (CRI): 85–98
• Illumination Depth: 50–180 cm
• Facular Diameter: 120–300 mm
• Dimming Control: 1%–100%
• Bulb Power: 61W
• Temperature Rise (Doctor’s Head): ＜1℃
• Input Power: AC100–240V 50/60Hz

Product Features

1. Ideal Cold Light EffectsAdopts new LED cold light source, energy-saving and environmental protection, service life up to 80,000 hours or more. Temperature rise on surgeon’s head is less than 1℃. No infrared or ultraviolet radiation, avoiding tissue damage and accelerating wound healing. Color temperature is constant, soft and close to natural sunlight, using imported OSRAM beads.
2. Excellent Shadowless EffectPetal-style three-dimensional design and multi-point light source ensure uniform illumination. Perfect shadowless effect even when partially blocked. Lamp disc turning radius ≥182cm, lamp head can be pulled down to vertical ground for flexible angle lighting.
3. Excellent Deep LightingComputer-aided modular design, multiple LED light columns focused for illumination, depth over 1200mm. Central illumination up to 160,000 Lux, color temperature adjustable 3500K–5000K, truly reflecting human tissue colors.
4. Advanced Control SystemLCD display button control, adjustable brightness for different surgeries. With illumination memory function for easy reuse.
5. Universal Suspension SystemRotating arm made of new alloy material. Balance system uses imported arm module, over 5 groups of universal joints, each cantilever with more than 3 joints rotatable 360°. Light structure, easy operation, accurate positioning, maximum adjustment range. Equipped with fatigue correction and positioning handle for long-term use.
6. Modern Laminar Lamp HeadGerman-designed petal ultra-thin structure, max thickness ≤10cm, excellent laminar flow effect. Middle handle is detachable, autoclavable at 134℃, easy to adjust and position flexibly.

Configuration List

1. Five-petal lamp with dimming system 1 suite
2. Rotating Arm 1 suite
3. Balance arm 1 suite
4. Transformer assembly 1 suite
5. Handle Sleeve 2 count
6. Hexagon allen key 1 suite
7. Fixed plate 1 piece
8. Install fixing bolts, washers, nuts 1 suite
9. Bracket, support cover 1 suite
10. Fixed seat 1 part
11. Product Qualification Certificate 1 part
12. Instructions 1 part
