Description

The horizontal autoclave, which adopted the way of gravity exchange to releasing the cold air from the chamber more completely to ensure the reliable sterilization. The control system automatically adjust the steam inlet and outlet according to chamber temperature during sterilizing. This unit is ideal equipment for hospitals, chemical, food, scientific research institutes and other organizations to sterilize surgical instruments, dressings, medicines, culture medium, food, fabric glassed etc.

Characteristics

1. Sterilizing course automatic sterilization controlled, easy to operate.
2. With drying function, suitable dressing drying.
3. With over-temperature, over-pressure auto-protect device.
4. The door opening mechanism cannot be operated until the pressure in the chamber is reduced to 0.027MPa. It can't be start on if the door doesn't close well.
5. The safety value will be open automatically when the inner pressure over 0.24MPa, and the steam be exhausting to the water tank.
6. The power will be cut-off automatically, cut-off the water and alarm when the machine lacking water.
7. The chamber of the sterilizer is made of stainless steel.

Technical data

Model

Sterilizing chamber volume φ480×850mm 150L

200L

φ515×1000mm

280L

φ600×1000mm

working pressure

working temperature

Adjustment of temperature 40℃- 134

Time of sterilization

Time of drying

Heat average

Power 9KW/380V 50Hz 9KW/380V 50Hz 12KW/380V 50Hz 18KW/380V 50Hz 18KW/380V 50Hz

Dimension (mm) 1400×600×1300 1400×670×1650 1400×770×1780 1430×880×1830 1800×900×1820 1400x770x1780

Transport dimension (mm) 1550x750x1850 1560x820x1850 1680x920*2100

G.W/N.W 320/240 KG 350/260 KG 465/365 KG 530/520 KG
