Description

Handheld Homogenizer

Product Features

Portable and lightweight with ergonomic design for easy manual operation. Speed adjustable from 8,000 to 32,000rpm. Dispersing shafts are made of 316L stainless steel, fully autoclavable, interchangeable, easy to disassemble and clean. Suitable for rapid homogenizing, emulsifying, suspending and disrupting biological samples such as animal tissue, bacteria, yeast and plant samples.

Technical Parameters

Speed range: 8000–32000rpm

Max circumferential speed: 6.3m/sec, 10m/sec, 14m/sec

Working volume: 0.1–50mL; 1–150mL; 1–250mL

Max viscosity: 5,000 mPas

Shaft material: 316L stainless steel, PTFE

Noise level: 72dB(A)

Protection class: IP20

Voltage: 110–120V/60Hz; 220–240V/50–60Hz

Power: 160W

Motor type: AC carbon brush motor

Dimension: 45mm×55mm×190mm

Weight: 0.54kg

Ambient condition: 0–40℃, 85%RH

Dispersing Shaft Specifications

Cat.No.18900543: Volume 0.1–50mL, max speed 6.3m/sec, for solid-liquid mixing and dispersing

Cat.No.18900815: Volume 1–150mL, max speed 10m/sec, for solid-liquid mixing and dispersing

Cat.No.18900544: Volume 1–250mL, max speed 14m/sec, for solid-liquid mixing and dispersing
