Description

Specification

I. Basic technical parameters

1. Spherical lens: -29.00 - + 26.75D (Step: 0.12D / 0.25D / 0.5D / 1D/ 2D / 3D)

2. Cylindrical lens: 0.00 - - 8.75D (Step: 0.25D / 0.5D / 1D / 2D / 3D)

3. Cylinder Axis: 0 ~ 180°(Step: 1/5/15/30/45 %)

4. Pupil Distance Far: 50-80 mm (Step: 0.5 / 1.0mm)

5. Working distance: 35 - 70 cm (Step: 5 cm)

6. Rotary Prism: 0 - 20 A (Step: 1 A /2 A)

7. Crossed Cylinder: Jackson Crossed Cylinder 0.25D

Jackson Crossed Cylinder 0.50D

8. Double cross cylinder (separating prism)

9. Retinoscopy Lens + 1.5D, + 2.0D (test distance 67cm, 50om)

II. Auxiliary lenses

1. Pinhole lens D 1mm

2. Markov lever Right eye (horizontal Markov lever), left eye (vertical Markov lever)

3. Red-green filter right eye (red), left eye (green)

4. Polarizing filter right eye (135 , 45 "), left eye (45 , 135 %)

5. Separation prism right eye (6 A BU), left eye (10 A BI)

6. Fixed Cross Cylinder Jackson Cross Cylinder 0.50D, Axis fixation 90

7.Vision 32

I. Data link with optometry series and focal length meter series;

IV. Light body and ultra-low sound;

1. Maximum size:

2. Host size:

3. Flat size:

600x400x200mm

360x85x360mm

247x179x4.68mm

4. Tablet resolution: 2860 1600

5. Flat screen:

6. Voltage:

7. Power:

8.Weight:

10.1 inches

AC 100-240V 50 /60Hz

90W

7.5kg

9. Packaging volume: 0.05 cubic

10.Packing slze:

520x450x220mm

11. Packaging material: aluminum alloy box
