Description

Semi Automatic ELISA Analyzer & ELISA Microplate Reader

The CCL-2100C is a reliable semi automatic ELISA analyzer and ELISA microplate reader designed for hospitals, diagnostic centers, clinical laboratories and research labs. As a professional 96-well microplate reader, it supports multiple tests on a single plate, fast reading speed, flexible test settings and accurate result management. If you are looking for a dependable laboratory ELISA reader or clinical laboratory analyzer, this model is an ideal choice.

Features of the ELISA Plate Reader

● Windows operation interface with graphic buttons and mouse operation

● Supports 96-well microplates and multiple tests on a single plate

● Test item arrangements in the microplate can be stored and reused

● Plate shaking function, with adjustable speed and time

● Open system: test items and parameters can be added or modified

● Large storage capacity for 1,000 test items and 1,000,000 results

● External large LCD color screen for easy operation

● Prints comprehensive reports including hospital information, patient information and test results

● External computer connection, easy to use and manage data

Specification of 96-Well Microplate Reader

Microplate types: 96-well plate, U-bottom, V-bottom or flat-bottom
Test mode: End-point, kinetic and multi-wave analysis
Light source: Tungsten halogen lamp, 12V/20W, more than 2,000 hours
Measuring system: 8-channel optical system
Wavelength: 405nm, 450nm, 492nm, 630nm; 4 additional filters optional
Measurement range: 0–4.00 Abs
Resolution: 0.001 Abs display, 0.0001 Abs internal calculation
Stability: <±0.005 Abs/10 min
Sensitivity: ≥0.01 L/mg
Linearity: r > 0.999
Repeatability: <0.3%
Reading speed: 5s for single wavelength, 10s for double wavelength
QC: Westgard multi-rule, automated QC alert
Self-checking function: Self-checking and calibration function
Printer: External inkjet printer, multi-format patient report
CPU: High-speed CPU
Interface: RS232, USB, PSTN and PC connection
Power supply: 220VAC ±15% or 110VAC ±15%, 50–60Hz, 100W
Working environment: Temperature 5℃–40℃; humidity ≤85%
Size: 43cm × 34cm × 16cm
Weight: 9kg

ELISA Reader Supplier and Price Information

China Care Medical is an experienced ELISA reader supplier, providing laboratory equipment for hospitals, clinics, diagnostic centers and medical distributors. For the latest ELISA reader price, product catalog or distributor quotation, please contact us directly.
