Product info
- Product name:Electrosurgical Generator with LigaSure Vessel Sealing Function
- Product code:CCS-HV200
Packaging Specifications
- Outer Packaging Size:0.6 × 0.45 × 0.3 m
- Gross Weight:0 kg
- Net Weight:6 kg
- Volume:0.08
Description
Electrosurgical Unit with Ligasure
Technical Features
The intuitive design and user-friendly set-up of the Electrosurgical Unit in the modern operating room. Monopolar and bipolar functions can satisfy all surgical demands with safety, flexibility, reliability and convenience.
With a wide 7-inch TFT LCD touch screen, clean and sharper image quality provides the user with easy access to all functions. The settings or modes of operation are changed by touching icons on the screen to ensure maximum ease of operation.
REM (Return Electrode Monitoring)
The REM system continually monitors patient impedance levels and deactivates the generator if a fault in the patient/return electrode contact is detected, which minimize the danger of burning incidents.
Real-time Monitoring and Instance Response System for Tissue Density
This proprietary technology delivers optimal clinical effects through continuous synchronization of current and voltage. It samples the current and voltage 450,000 times per second, enabling it to respond to tissue impedance changes in less than 10 milliseconds. This ensures the machine achieves optimum energy output levels quicker and more accurately, delivering only the precise voltage needed safely to each tissue type.
Automatic Self-Test
Once switched on, the system performs a comprehensive internal test.
Ligasure (Vessel Sealing)
The machine enables permanent sealing of blood vessels with a diameter up to 7mm with this technology under bipolar coagulation.
Technical Specification
- Main Frequency: 512 KHz
- Power Supply: 100-240V / 50-60Hz
- Dimension: 47*34*17cm
- Weight: 6KGS
- High Frequency Leakage: Monopolar: <150mA; Bipolar: <60mA
- Low Frequency Leakage:
Working Modes
| Working Mode | Sub-mode | Max. output power | Rated Load |
|---|---|---|---|
| Monopolar Cut | Pure Cut | 200 W | 500 Ω |
| Blend Cut I | 180 W | 500 Ω | |
| Blend Cut II | 150 W | 500 Ω | |
| Monopolar Coagulation | Soft Coagulation | 150 W | 500 Ω |
| Fulgurate Coagulation | 120 W | 500 Ω | |
| Spray Coagulation | 100 W | 500 Ω | |
| Bipolar Coagulation | Standard Coagulation | 150 W | 100 Ω |
| Precise Coagulation | 60 W | 100 Ω | |
| Ligasure Vessel Sealing | - | 200 W | 25 Ω |
Accessories
- Disposable ESU Pencils
- Disposable ESU Plate
- Reusable Plate Cable
- Two Button Footswitch
- Bipolar Forceps
- Bipolar Forceps Cable
- Ligasure instrument:
- The machine is compatible with Convidien Brand Instruments.
