Description

Product Material

The main body of the equipment adopts high-strength aluminum alloy profile, circular arc design, no sharp corners on the surface, environmentally friendly plastics, electrostatic spraying, matte treatment, anti-corrosion, easy to clean and disinfect, using Angle contact ball bearing, running more smoothly. Net load: equal to or equal to 150Kg.

Arm

Arm length 1000 mm (the length can be customized according to customer's require), up to 8 mm, the thickness of tower body rotation Angle: a minimum of 340 °.

Motorized

The vertical lifting range of the table is ≧400MM; the button is on the table control handle.

Console

Length 800mm (can be customized according to user requirements), rotation 340 degrees, gas-electric separation design.

Power socket

6 universal power sockets, working power: 220V 50HZ 10A, Equipotential/1pc. Network socket 1/pc.

Gas terminal

Oxygens/1nos,Vac/1nos,CO2/1nos,different shapes to avoid improper insertion, the number of inserts is greater than or equal to 20,000 times

Platform

2pcs trays, 550420mm, easy to clean and disinfect. Round Angle anti-collision design, height adjustable, with 2 standard side rails 1025.

Drawer

Drawer 1pc, engineering plastic molding, automatic reset device.

Gas tube

Import gas pipeline, provide inspection report according to medical grade.

Infusion support

Stainless steel infusion rack 1 set, adjust height is not less than 800mm

Mechanical damping brake

Mechanical damping brake, even in the absence of electricity, gas, equipment will not produce drift
