Product info
- Product name:Portable defibrillator with external defibrillation
- Product code:CCD-Defi5s
Packaging Specifications
- Outer Packaging Size:0.38 × 0.32 × 0.21 m
- Gross Weight:3.5 kg
- Net Weight:0 kg
- Volume:0.03
Description
CCD-5s+ Automatic External Defibrillator (AED)
Core Overview
CCD-5s+ is a high-performance, multi-functional automatic external defibrillator with humanized operation design and comprehensive safety features, specially designed for cardiac emergency resuscitation. It supports adult/child dual modes with selectable energy sequences, is equipped with voice/visual dual guidance, and has automatic self-test, infrared data transmission, ECG storage and printing functions. The device features simple operation steps, loud and clear voice prompts, water-resistant buttons and a portable design, suitable for public places, medical institutions and emergency rescue scenarios, and can guide non-professionals to complete defibrillation operations quickly and accurately.
Core Technical Specifications
Basic Performance & Defibrillation Parameters
| Category | Parameter Details |
|---|---|
| Self-test | Daily/Weekly/Monthly automatic self-test |
| Working mode | Adult/Child dual mode (one-key switch) |
| Waveform type | Biphasic truncated exponential |
| Max energy | 200 Joules |
| Energy sequence | Child Mode: 50/50/75 Joules; Adult Mode: 150/150/200 Joules (energy selectable 50J-200J) |
| Charge time (25°C, new machine) | ＜6s to 150J; ＜8s to 200J |
| Guidance mode | Extensive voice prompt + color LED visual indicators (step-by-step guidance) |
| Control buttons | 2 key design: ON/OFF, Shock (flashing prompt when shock is needed) |
Data & ECG Functions
- ECG storage: 1,500 events recordable
- Data transmission: Infrared transmission (supports connection with Meditech AED storage software)
- ECG waveform setting: Gain (5mm/mv/10mm/mv/20mm/mv); Speed (12.5mm/s/25mm/s/50mm/s)
- Printing function: Previewable print page, supports basic information printing
- Software functions: ECG wave reading/setting, AED language setting, data reading/analysis/deletion; case management (ACCESS database storage, data import/export)
- Memory playback: Displays device running status (event type/time/description/waves), including impedance, charging voltage, shock advice results, etc.
Physical & Environmental Parameters
| Category | Parameter Details |
|---|---|
| Power supply | 12V, 2800mAh Li-MnO₂ non-rechargeable battery (4×2 CR123A, 2.8Ah) |
| Dimensions (L×W×D) | 300mm×240mm×80mm |
| Weight (with battery) | 1.9Kg (4.2 Pounds) |
| Operating temperature | 0°C to 40°C |
| Operating humidity | 30%-95% (non-condensing) |
| Storage temperature (no battery) | -20°C to 55°C |
| Storage humidity (no battery) | Up to 93% (non-condensing) |
| Buttons | Water-resistant design + soft texture |
Standard Accessories
Soft hand carry case, reflective sign, speaker protection, transparent panel, THE PAD protector socket, 12V non-rechargeable battery, disposable defibrillation pads (for adults/children ＞20kg/55Ibs)
Core Product Advantages
- Simple & Intuitive Operation: 2-key minimalist design, step-by-step voice + LED visual dual guidance, written operation instructions on the device; even non-professionals can complete defibrillation in 4 simple steps, suitable for emergency scenarios with no professional medical staff on site.
- Dual Mode & Precise Energy Control: Independent adult/child mode button; child mode reduces energy to 50/50/75J (in line with international resuscitation guidelines) to avoid heart muscle burns, and energy sequence is selectable for different age groups and emergency situations.
- Fast & Efficient Defibrillation: Ultra-fast charging speed (＜6s to 150J, ＜8s to 200J), realizes rapid rescue; biphasic truncated exponential waveform ensures high defibrillation efficiency and low damage to the heart.
- Comprehensive Self-test & Safety: Daily/weekly/monthly automatic self-test, real-time monitoring of device status, ensuring it is always in standby for emergency; water-resistant buttons, stable performance in various environmental conditions.
- Clear & Audible Prompt: High-quality loud speaker with 5 levels of volume adjustment, clear voice instructions even in noisy public places; color LED indicators for each operation step, double guarantee for operation guidance.
- Powerful Data Management: 1,500 events ECG storage, infrared data transmission, matching professional storage software; supports ECG waveform adjustment, case management, data printing and playback, convenient for post-rescue analysis and medical record archiving.
- Portable & Practical Design: Light weight (1.9Kg) and compact size, easy to carry and store; can be used directly in the carry case, no need for complicated unpacking in emergency; disposable pads are suitable for adults and children over 20kg, with strong versatility.
- Multi-scenario Applicability: With 2 optional languages, adaptable to different regions; stable performance in a wide temperature/humidity range, suitable for public places (stations/malls), medical institutions, community health centers, emergency vehicles, etc.
Simple 4-Step Operation Process
- Start the device: Press the ON/OFF button, and the voice instruction starts immediately to guide subsequent operations.
- Attach the pads: Stick the disposable defibrillation pads to the patient, and the AED will automatically start ECG analysis (the device only proceeds to the next step when the pads are attached properly).
- Energy selection: The device automatically matches adult/child energy sequence (one-key switch mode), no manual complex setting required.
- Deliver shock: If shock is needed, the Shock button flashes with voice prompt; press the button to deliver electrical shock to the patient for resuscitation.
