Product feature

1. Active and passive modesIt can be used for training lower limbs and realize automatic conversion between active and passive modes.
2. Spasm protectionFor the patient with excessive muscle tension, the automatic rehabilitation instrument will automatically stop and run slowly to the opposite direction.
3. BiofeedbackLower limb training on the basis of intelligent training to increase the pedal adjustment and bio-feedback function in operation, the speed of automatic rehabilitation machine can be adjusted according to the degree of joint stiffness or muscle tension, thus it would not cause secondary damage.
4. Evaluation functionIn the end of operation, the evaluated result will be automatically displayed to facilitate the real-time monitoring of the patient's condition and be helpful in clinical research.
5. Case storage functionConvenient for the patient's conditions record and before-after contrast.
6. Automatic rehabilitation machine with length and height adjusting mechanism can meet different leg length and body height requirements.

Parameter

• Dimensions: 630mm × 480mm × 1110mm
• Output power: 80VA
• Input voltage: AC 220V
• Fuse: 2A 5 × 20mm
• Movement speed: 5rpm-55rpm continuously adjustable
• Treatment time: 0min ~ 60min adjustable
• Spasticity: 1-3 level adjustable
• Spasm time: 2s-28s adjustable
• Armrest section: 0~70mm adjustable
• Motor output power: Be divided into high, medium and low 3 levels
