Description

Specifications

Type: TableTop Speed Type: High Speed (≥10000rpm) Max speed rpm: 18000 Refrigerated Function: With Refrigerated Function Application: Beauty, Hematocrit, Cell Smear

Features
1,The shell adopts steel structure,which is simple-compact,light-weight and low-noise.
2,Adopt advanced CPU control system to realize microprocessor control of rotate speed, temperature and RCF.
3,With stainless steel structure, guard ring around chamber.
4,Protection for door lid, over speed, imbalance and over-temperature.
5,With CFC gas libre.
6,LCD display, easy to operate.

Technical Parameters:

Model   CCL-TGL18

Max Speed   18000r/min

Max RCF       18860xg

Max Capacity   36 x1.5/2ml

Speed Accuracy   ±50r/min

Temp Accuracy   ±1°C

Temp Range   -20°C ~ +40°C

Timer Range   0~99min

Motor       Convert motor

Noise   ≤60dB(A)

Power Supply   AC220v&110V 50Hz 18A

Dimension   600x330x300mm(L*W*H)

Weight   40kg

Rotor Optional:

Rotar Model	Capacity(ml)	Max speed	Max RCF (×g)
Rotar Model	Capacity(ml)	(r/min)	Max RCF (×g)
No.1	12×0.5ml	18500	19920
No.2	12×1.5/2.2ml	16000	17800
No.3	24×1.5/2.2ml	14000	18860
No.4	3×8×0.2ml PCR	15000	14750
No.5	36×1.5/2.2ml	11000	10800
No.6	18×0.5ml	16000	15450
No.7	12×5ml	12000	10560
No.8	48×0.2/0.5ml	12000	11060

Rotor en option:
Modèle Rotar Capacité (ml) Vitesse max. RCF max. (× g)
(r / min)
N ° 1 12 × 0,5 ml 18500 19920
N ° 2 12 × 1,5 / 2,2 ml 16000 17800
N ° 3 24 × 1,5 / 2,2 ml 14000 18860
N ° 4 3 × 8 × 0,2 ml PCR 15000 14750
N ° 5 36 × 1,5 / 2,2 ml 11000 10800
N ° 6 18 × 0,5 ml 16000 15450
N ° 7 12 × 5 ml 12000 10560
N ° 8 48 × 0,2 / 0,5 ml 12000 11060
