Description

II. Technical Specifications

1. Power Source: 220 V 50 Hz / 110 V 60 Hz
2. Temperature Control Range: Room Temperature to 60 °C (precision ≤ ±1 °C, LED display)
3. Rotating Speed: 30–360 rpm
4. Timing Range: 0–120 minutes
5. Oscillation Amplitude: ≥ 20 mm
6. Working Load: 12 kg
7. Working Method: Continuous operation

III. Method of Application

• The instrument uses an alternating current power source (220 V). Before use, ensure the outlet has a current rating of at least 6 A and a safety grounding device. Replace the outlet if these conditions are not met.
• Open the cover, and clamp the vessel requiring oscillation in the spring multipurpose clamp.
• Turn on the power switch and the oscillation operating switch.
• Select the desired oscillation speed and operating temperature. Adjust the oscillation speed from slow to fast.
• Control the temperature using the temperature display unit. Indicator lights guide the operating mode:
