Description

Medical Suction & Irrigation Unit

Normal running conditions

1. Temperature of Environment: 10°C~45°C
2. Relative Humidity ≤80%
3. High Atmospheric Pressure: 86~106 kPa
4. Power: 230±10VAC, 50-60Hz, 1000VA
6. Easy to repair.
7. Dimension(mm): L/W/H:740/435/860
8. WEIGHT: 42KG
9. Package size: 940/590/1000(mm)
10. WEIGHT:62KG
11. Frame Material: ABS

Technical Parameter

1. Spray rod, positive pressure of blow device: 0.1Mpa—0.15Mpa; (Adjusting)
2. Negative pressure of suction lube: ≥0.07Mpa; (Adjusting)
3. Suction vacuum pump: 370W; 2500CC main suction apparatus 1pc
5. Compressor pump: 80W, 1 pc
6. Power: 230±10VAC, 50-60Hz, 1000VA
7. Preheated anti-fog apparatus: 300W

Configuration

Standard Set
