Description

Hospital Bed Specifications

1. Product Dimension: 21601070450/750MM
2. Optional locking switches for headboard and footboard; anti-collision wheels installed on both head and foot ends for safer application
3. Sprayed plastic bed board with concave air vent design, excellent air permeability to effectively prevent bedsores
4. Adjustment Range: Backrest lifting angle up to 80°, foot section lifting angle up to 45°, overall height adjustable from 450MM to 750MM
5. Load Capacity: Total bed load 600kg, maximum dynamic load of backboard 150KG
6. Curved guardrail: Tube specification ∮19*1.2mm; equipped with bidirectional limitless protection device to extend service life and improve safety
7. Anti-collision wheels: Central wheel made of imported ABS engineering plastic; wheel size Ø100MM, thickness 50MM, inner hole Ø50MM; plastic pin part length 81MM, width Ø81MM, matched with 60601.5MM cross beam
8. Casters: 6-inch central control wheels with TPU polyurethane surface, silent and wear-resistant; central braking system matched with aluminum alloy foot pedal
9. IV pole: Manual two-stage telescopic structure, adjustable height from 1000mm to 1600mm
