Description

Specifications

Methodology

Spectral domain OCT

≤ 6 um (in tissue)≤20 um (in tissue)> 2.5 mm (in air)

Axial resolution

Transverse resolution

Scan depth

>6mm

Scan range

Scan speed

> 24,000 A-scans/sec, up to 36,000 A-scans/sec

3D, Raster, Circle

Scan modes

Fundus image

OCT en face

Focus adjustment

-15D to +15D>3mm840 nm SLD750 uW (at cornea)

Pupil diameter

OCT light source

Optical power

Operation

13.3" touch screen, optional external mouse or keyboard

Power supply

100-240 V,50/60 Hz

Dimensions

497 mm X 395 mm X 490 mm (LXWXH)

Weight

34kg (75lbs)
