Product info
- Product name:Desktop high and low speed refrigerated centrifuge
- Product code:C260401004
Packaging Specifications
- Outer Packaging Size:0.85 × 0.77 × 0.6 m
- Gross Weight:100 kg
- Net Weight:85 kg
- Volume:0.39
Description
C260401004 Benchtop High & Low Speed Refrigerated Centrifuge
Main Features
- Three-in-one multifunctional benchtop refrigerated centrifuge: large-capacity low-speed routine separation & cell collection; universal separation of cell lysate; micro centrifugation for DNA precipitation.
- High-strength steel body structure, higher safety and reliability.
- Fluoride-free compressor with dual-circuit refrigeration system, excellent heat exchange efficiency, eco-friendly pollution-free, precise temperature control, one-touch pre-cooling to boost working efficiency.
- High-performance variable frequency brushless motor, stable running, maintenance-free, high torque, fast acceleration and deceleration.
- Precise microcomputer processor control; 7-inch LCD touchscreen real-time displays runtime, working status, speed, temperature, timing, acceleration/deceleration rate, program mode, jog function and all other parameters; touch operation for all settings.
- Editable parameters during operation; simultaneous display of rotation speed and RCF on single screen, independent switching between speed mode and centrifugal force mode.
- Customizable acceleration target speed mode, equipped with instant short-spin jog function.
- Humanized operation system: stores & retrieves up to 99 groups of user programs; freely editable gradient operation programs with 10 acceleration segments and 10 deceleration segments to customize speed curves; supports storage of maximum 1,500 historical test records.
- Complete safety mechanisms: electronic interlock door lock with emergency manual unlock; overspeed, overtemperature and unbalance auto-protection; automatic power-off protection with error code display when abnormality occurs, including fault explanation and troubleshooting guidance.
- Auto rotor identification system: compatible with abundant rotor types, automatically identifies rotors to avoid overspeed operation caused by misoperation for enhanced safety.
- Inductive self-suction electronic door lock: lightly press the lid for automatic adsorption; integrated shockproof design, supports both auto unlock and manual lock.
Technical Specifications
| Item | C260401004 |
|---|---|
| Max Speed | 18500 RPM, stepless adjustable |
| Max RCF | 23980xg |
| Timer Range | 0–99h 59min 59s |
| Max Rotor Capacity | Swing rotor: 250mL × 4 |
| Temperature Control Range | -20℃ ~ 40℃ |
| Temperature Control Accuracy | ±1℃ |
| Speed Accuracy | ±20r/min |
| Power Supply | AC220V 50Hz |
| Machine Dimension (L×W×H) | 755×670×410 mm |
| Package Size | 850×770×600 mm |
| Gross Weight / Net Weight | 100kg / 85kg |
Plain Text Version for Product Page
Features:
Benchtop high-low speed refrigerated centrifuge with three-in-one functions: large capacity low-speed routine centrifugation & cell collection, universal separation of cell lysate, micro centrifugation for DNA pellets.
High-quality steel frame for safer and more stable operation.
Fluorine-free dual-cycle refrigeration compressor with powerful heat exchange, environmental friendly, precise temperature control and one-key pre-cooling function.
Efficient variable frequency brushless motor, stable operation, maintenance-free, high torque, rapid speed rise and fall.
Adopts microcomputer precise control, 7-inch LCD touch screen to display time, working status, speed, temperature, timing, acceleration/deceleration, program mode, jog function and other parameters with touch control.
All parameters can be adjusted during operation; speed and relative centrifugal force are shown on one screen, two operation modes can be switched separately.
Customizable target speed mode for startup/stop, with instant centrifugation jog function.
User-friendly design: stores 99 sets of editable programs, freely programmable gradient operation curves with 10 acceleration and 10 deceleration segments; saves up to 1500 historical test records.
Full safety design: electronic door lock with emergency unlock; auto protection against overspeed, overtemperature and imbalance. The machine will auto shut down with error code, fault description and handling tips once abnormal.
Auto rotor recognition system supports multiple rotors, prevents overspeed running caused by wrong rotor installation.
Inductive self-priming electronic door lock, shockproof design, easy to close, compatible with automatic and manual unlocking.
Technical Parameters:
Model: C260401004
Max Speed: 18500 RPM, stepless speed regulation
Max RCF: 23980xg
Timer: 0-99H59min59s
Max rotor capacity: Swing rotor 250ml×4
Temperature control range: -20℃~40℃
Temperature control accuracy: ±1℃
Speed accuracy: ±20r/min
Voltage: 220V 50Hz
Dimension(mm):755x670x410
Package(mm):850x770x600
G.W./N.W.: 100/85KG
