◆ Function of load-bearing, Blood bag weight deducted and Liquid production control.
◆ Functions of pallet swing, alarm, proximity control, swing stop and swing automatic recovery
◆ Eliminates the man-made error and provides convenience for the production of plastic bags
◆ suitable for various blood sampling mechanism
◆For blood stations,hospitals and other units to separate the use of plasma
●After bags in the blood is layered
●Points pulp clamp pressure can make the different composition of bood top-down being squeezed out.heating constant temperature function
| Model | BMC-1200B |
| range | 0-1200ml |
| division value | 1ml |
| Liquid production rate | 0.5--3ml/s |
| Liquid production error | ±5% |
| Liquid specific gravity | 1.05g/mL |
| Oscillation frequency | 30-32rpm |
| Swing angle | 13±2 |
| Power | 40W |
| Alarm and block | Sound light alarm and block |
| Block applied piping | external diameter: Ø3~Ø6mm, thickness:0.5mm |
| Block thrust | ≤14N |
| Voltage | 110V 60Hz/ 220V 50Hz |
| Dimension(mm) | 280×230×210 |
| Package (mm) | 350×300×260 |
| Weight | 5.5/5kg |
