Description

Enhanced Hardware Platform

1. 19MHU High‑Power X‑Ray Tube Tube heat capacity reaches 19MHU, with built‑in internal energy system; No pre‑heating required within 8 hours, working efficiency increased by up to 280%; Applied technologies: A‑STAR AI X‑ray tube, LMB technology, extra‑large anode surface, AI micro‑etching technology, AI adjustment to reduce electronic noise, balancing long service life and favorable cost‑effectiveness.
2. A‑STAR Detector Integrated PIN and analog‑to‑digital conversion chip greatly improves overall unit stability, featuring excellent expandability and reusability to lower operating costs; Adopts ultra‑low‑power ASIC chip to reduce channel power consumption, heat accumulation and temperature fluctuation, ensuring stable image quality; High‑standard grating structure delivers lower electronic noise and high‑definition images even under low‑dose scanning conditions.

Exclusive Care Design

Designed for medical staff operation and patient experience, supporting single‑operator scenarios to improve patient cooperation and examination comfort.

A‑Touch Operating System: Patient registration and scan protocol selection can be completed via remote tablet;

Intelligent Positioning System

Whole‑body organ recognition, collision detection, positioning consistency verification, posture adjustment, intelligent examination table movement, automatic scan range definition;

Rapid positioning of human anatomical points, i‑centering automatic high‑precision alignment;

Supports wireless control. Medical staff can operate close to patients inside the gantry room. Wheelchair‑bound patients can conveniently finish scan preparation for optimized workflow efficiency.

O Dose Low‑Dose Platform

Following the ALADA (As Low As Diagnostically Achievable) principle to achieve high‑quality images at low dose. Technology suite includes:

240° exposure, Organ‑Safe organ protection, ClearInfinity deep‑learning reconstruction, Auto kV automatic kilovoltage, 3D dose modulation, A‑STAR detector, ECG cardiac dose modulation, pediatric‑dedicated scan protocols, dose verification function.

Extreme HD Imaging

Core hardware parameters: 19MHU X‑ray tube, 50kW generator, 32‑row detector;

Gantry rotation speed: 0.48 seconds per rotation; Spatial resolution: 22lp/cm;

Scan FOV: 250mm; Matrix: 1024×1024; Temporal resolution: 25ms;

ClearInfinity Deep‑Learning Reconstruction Technology: AI‑based CT reconstruction technology balancing ultra‑low radiation dose and superior image quality. It inputs low‑dose raw data, learns from high‑dose high‑quality reference data, and outputs high‑quality images at low dose. Breaking limitations of conventional FBP reconstruction to obtain high‑resolution images with authentic textures.

Excellent Clinical Performance

Equipped with DAT diagnostic assistant tools for various complex clinical scenarios:

1. Cardiac Applications Cardiac function analysis, coronary artery calcium scoring, coronary artery analysis; Arrhythmia processing tool: guarantees coronary image quality under high heart rate and arrhythmia conditions; functions include arrhythmia correction and coronary motion elimination.
2. Other Clinical Applications Carotid artery CTA, Prism imaging, large‑range perfusion imaging; enables 3D visual quantitative evaluation of lesions such as gout, outputs quantitative data including lesion volume to assist diagnosis.

Key Technical Specifications
