Description

Bed Body Dimensions: 2160*1150*470/770mm Materials:
▪ ead and foot sections resistant to acid, alkali, oxidation, and corrosion
▪ Bed board made of cold-rolled steel formed by single pressing, with electrostatic powder coating
▪ Amcan-style PP side rails with die-cast aluminum main frame, equipped with assist springs for smooth operation, sturdy and durable; logo stickers are customizable
▪ Bed frame welded from formed s, providing stronger load-bearing capacity and stability
▪ System uses Danish LINAK safety voltage motor
Standard Configuration:
▪ Advanced motor system (4 motors, 1 control bontrol handle)
▪ American-style 4-piece PP side rails
▪ 1 set of head and foot sections, 4 anti-collision wheels
▪ Taiwan central control foot wheels with eous braking system
▪ 2 infusion stand sockets and 2 drainage hooks on each side, 1 infusion stand
Functions:
▪ Height adjustmen: 470mm--770mm
▪ Backrest angle: 0-80°(±5°)
▪ Knee angle: 0-40°▪ Tilt angle: 0-12°
Load Capacity: 250kg
