Description

Description

• Two models available:

Blood Gas Analyzer - Specification

Sample

• Whole blood, Serum, Plasma, Dialysate, CSF
• Model name: Gxilite80

Input Parameters

• Patient Temperature
• Hemoglobin
• FiO₂
• B.P

Measured Parameters

Derived (Calculated) Parameters

• pH, pCO₂, pO₂, temperature corrected
• HCO₃⁻, Total carbon dioxide
• BE (Actual/Blood excess)
• SBC (Standard bicarbonate)
• ABE (Actual base excess)
• Ca (Total calcium concentration)| Ca (Ion)                | Ionized calcium concentration | mmol/L|| TCO₂                    | Total carbon dioxide          | mmol/L|| AG (Anion gap)          | Anion gap calculation         | mmol/L|| p50                     | Oxygen tension at 50% Hb saturation | mmHg || RQ                      | Respiratory quotient          | -     || AaDO₂                   | Alveolar-arterial oxygen difference | mmHg || QS/QT                   | Shunt fraction                | -     || O₂HB                    | Oxygen saturation             | %     || DBS                     | Dose based substitution       | -     |

Interface

• Serial Line RS-232
• TCP/IP interface
• Integrated Bar-code reader

Analysis Time

• <90s

Sample Volume

• 95μL Whole blood
• 35μL Capillary blood

Calibration

• Automatic, programmable
• 1-point and 2-point calibration

Data Storage

• 10000

Display

• 10.4" TFT touch screen

Battery

• Lead Acid Battery, 2.3 Ah

Printer

• Build-in Thermal printer, 70mm

Barcode Reader

• Up to 24 kinds barcode type

Dimension

• Instrument: 400(W)×574(H)×344(D)mm
• CAL PAK: 250(W)×180(H)×700(D)mm
• AUTOQC: 100(W)×180(H)×700(D)mm

Weight

• 18kg

Work Environment

• 15℃~30℃

Storage Environment

• 5℃~40℃

Power Supply

• 100-240V~50/60Hz

Certifications

• CE
• TUV
