- Description
Specifications
Type:
TableTop
Speed Type:
Low Speed (≤10000rpm)
Max speed rpm:
4000
Application:
Hematocrit, Cell Smear
◆ Economical: 3 types of rotors can be equipped on one instrument;
◆ Three types of rotors are available for conveniently use: Angle rotor, swing rotor for red blood cell washing, and swing rotor for micro-column gel test.
◆ Simple operation: 11 programs have built-in and another 30 programs can be set accordingly. Standard programs for different tests of blood group serology, and more programs can be built in according to the customers requirements for normalization & standardization of clinical check and research.
◆ Accuracy of RCF: quickly start, prompt speed reaching and automatic braking.
◆ Wide application: It can be used for normal-test of blood group serology, red blood cell washing(easy tube washing)and micro-column gel test. Six joint tubes make operation simple and easy and the centrifugal time is greatly shortened for prompt determination of the result.
Technical Parameters
Max Speed |
4000r/min |
Voltage |
110V/220V+22V |
Speed Accuracy |
±30rpm |
Power |
57w |
Time | 0-99min |
Frequency |
50HZ |
MaxRCF | 3840xg |
Weight |
18kg |
Noise | ≤42dB | ||
Dimensions | 480mmx360mmx280mm(LxWxH) |
Optional Rotors
No.1 Angle Rotor,

Capacity: 12×10ml, Max Speed: 4000 r/min, Max RCF (×g):2200
No.2, Red cell washing rotor,

Capacity: 12×10ml, Max Speed: 3000 r/min, Max RCF (×g):1790
No.3, Microcolum gel cards rotor,

Capacity: 12×6 colum, Max Speed: 3000 r/min, Max RCF (×g):1790
No.4, Microcolum gel cards rotor,
Capacity: 24×6 colum, Max Speed: 3000 r/min, Max RCF (×g):1790
