MODEL: C260228001
Use
The table type sterilizers are safely auto-controlled,whichare designed for the dental clinics,hospitals,school lab,scientific research institutions and laboratory.And mostlysuitable for sterilizing of surgical,dental and eye instruments,glassware medicine,culturemedium and biological dressing,food,etc.
Characteristics
◆Standard ClassB with three times vacuum and drying,the remaining temperature of sterilized instrumentis less than 0.2%.
◆LCD display working status,touch keys.
◆ The vacuum data can reach-0.8bar,it fits various instrument,including package,unpackaged,solid,hollow,
multi-apertures and inset pipes.It makes sure the instrument can be sterilized completely.
◆ Fully computer controlled LCD display bright show.The interface is modularized panel for easy operation.
◆It is installed with BOWIE&DICK which measures the penetration of water steam.
◆ It has vacuum test which can make sure the ability of vacuum testing.
◆Fast and independent steam generator.
◆ Built-in mini printer which can record the sterilizing information.
◆ Equipped with Safety valve,Safety lock door system,Pressure lock system,Pressure or temperature overload protection,Alarm system.
◆It inactivates the HIV,HBV,BSE,and bacillus efficiently.
◆ This product is designed for open water tank,water purification,sewage tank separation,convenient and intuitive.
◆ The cycle cannot be started if the door is not sealed.Once the cycle is started and running,the sealed door is locked and cannot be opened to ensure operational safety.
PARAMETER
| Model | 18L | 23L |
| Chamber Volume: | 18L(φ250×360 mm) | 23L(φ250×470 mm) |
| Max working temperature: | 138℃ | 138℃ |
| Max working pressure: | 0.25mpa | 0.25mpa |
| Adjusted sterilizing temperature range: | 55℃~134℃ | 55℃~134℃ |
| Adjusted timer range: | 0~99mins | 0~99mins |
| Adjusted drying time range: | 0~99mins | 0~99mins |
| Heat average: | ≤±1℃ | ≤±1℃ |
| Power: | 2KW/AC220V/50HZ | 2KW/AC220V/50HZ |
| Dimension: | 480*680*455mm | 480*680*455mm |
| Transport dimension: | 580*790*580mm | 580*790*580mm |
| Gross/Net Weight | 56kg/47kg | 57kg/53kg |
