Product info
- Product name:Full Automatic Uncap Centrifuge
- Product code:CCL-L420
Packaging Specifications
- Outer Packaging Size:1 × 0.77 × 1 m
- Gross Weight:177 kg
- Net Weight:0 kg
- Volume:0.77
Description
Breif introductionOur product is a special design for hospital, blood station, radio-immunoassay and nuclear medicine. It can complete all action at a time and solve the difficulty of uncap in separation of vacuum blood tube, which to be the most advanced and efficient separation machine. Features:
- Greatly improved the work efficiency and avoided the re-mix of blood after separation.
- Completely eradicated bacteria infection and It is suitable for every capacity of evacuated blood tube.
- Microprocessor control and AC conversion motor, with high speed accuracy and 100% uncap rate.
- Large LCD display, showing RPM, RCF, Speed, Running Time, Errors.
- Adapter with double unique design to avoid caps dropping during running.
Technical parameters
| Max Speed | 4000r/min | ||
| Rotor | Rotor | Max Speed | RCF |
| NO.1 Swing Rotor | 96×5/7ml | 4000r/min | 3840×g |
| NO.2 Swing Rotor | 124×5/7ml | 4000r/min | 3840×g |
| NO.3 Swing Rotor | 148×5/7ml | 4000r/min | 3840×g |
| Motor | Microprocessor Control, AC Frequency Motor | ||
| Timer Range | 0~99min | ||
| Noise | ≤65dB(A) | ||
| Power Supply | AC220V & 110V 50-60Hz 5A | ||
| Dimension | 800×600×820mm(L×W×H) | ||
| Weight | 120KG/150kg(Refrigerated Function) Rotors | ||
| Rotor Model | Capacity(ml) | Max speed | Max RCF (×g) |
| (r/min) | |||
| No.1 SR | 108×5/7ml | 4000 | 3600 |
| No.2 SR | 148×5/7ml | 4000 | 3680 |
