Feature:
1.Can be used in ward and emergency treatment room for fluoroscopy and radiography.
2.X-ray generator is combined.
3.Single focus, bridge rectification.
4. It is precise, safe, reliable and flexible.
5. Remote control device (control range≥5 m) is used.

Main technical parameter:

X-ray generator	Stationary anode, single focus, and bridge silicon  rectification, The X-ray generator is an oil-immersed self-cooled unit.
Max rated capability	Fluoroscopy			75kVp，3mA
	Radiography			90kVp，50mA
Power supply	Voltage			180～240V
	Frequency			50Hz
	Power			not lower than 3.5kVA
	Resistance			not larger than 1Ω
Voltage adjustment range  of x-ray tube	45～90kVp  (divided into 10 steps)
Range of the timer	0.08～6.3 s
Fluorescent screen size	280mm×350mm
Distance between the focus  to the screen	620mm
Tube head carriage  movement range	(vertical): 950 mm
	(horizontal): 160 mm
X-ray tube focus transverse  rotation	±60°
Specification of X-ray tube	XD3-3.5/100,Stationary anode, single focus 2.6mm
Transport dimension，Weight	1175×870×2050(mm),(NET)150kg/(GROSS)244kg
