- Description
Specifications
Temperature:
-86 degree
Volume:
408 Liters
| Model | CCL-86408 |
| Model | CCL-86408 |
| Shelf/drawer QTY | Stainless steel shelf/3 |
| Cooling method | Direct cooling |
| Defrost | Manual |
| Refrigerant | R290 & R170 |
| Energy consumption(kWh/24h) | 11.6 |
| Noise（db) | 50 |
| Ambient temperature（℃） | 10~32℃ |
| Temperature range（℃） | -60~-86℃ |
| Compressor brand/QTY | SECOP/2 |
| Evaporator | Submerged coil evaporator |
| Evaporator material | Copper tube evaporator |
| Condenser | Copper tube and finned |
| Sensor | PTC |
| Temperature controller | Microprocessor |
| Display | Digital display |
| Voltage/frequency（V/Hz) | 220/50Hz |
| Power（W) | 845W |
| Current（A) | 7 |
| Inside material | Stainless steel |
| Outside material | Color sprayed steel |
| Insulation | PURF |
| Capacity（L/cu.ft) | 408 |
| NT./GT.（kg) | 215/245 |
| Exterior size(W*D*H)(mm) | 872×1028×1945.5 |
| Interior size(W*D*H)(mm) | 606×575×1180 |
| Package size(W*D*H)(mm) | 954×955×2094 |
| High/low temperature | √ |
| Power failure | √ |
| Abnormal voltage | √ |
| Sensor error | √ |
| Low battery | √ |
| Condenser clean | √ |
| High ambient temperature | √ |
| Door ajar | √ |
| Foot | / |
| Castor | √ |
| Inside door | 2 |
| Test hole QTY/diameter | 1/25MM |
| USB port | √ |
| Chart recorder | Optional |
| Data logger | Optional |
| Power failure backup system(alarm) | 72h |
| Remote alarm port | √ |
| CO2 back up system | Optional |
| LN2 back up system | Optional |
| Certification | ISO |
| 2' boxes | 288 |
| 3' boxes | 192 |
Shipping Information:
G.W: 245kg
Packing Size: 0.954m,0.955m,2.094m
Unit: Piece
Special: No
